DC Audio

Level 1 Subwoofers

Level 1 Subwoofers

$99.99 USD
$99.99 USD
Sale Sold out
Shipping calculated at checkout.
Ohm
Size

DC Audio m4 Level 1 Subwoofer

Sizes Available: 10 & 12 Inch Models

Ohms Available: D2 & D4 Models

Power Handling: 300 Watts RMS 600 Watts Peak



The Long-awaited Level 1 Subwoofer is finally here!

It starts out with a double stacked FEA optimized motor. A chrome top plate and T yoke. 2.0" voice coil, Glossy Black stamped Steel Frame, push terminals.

This subwoofer works great in sealed or ported enclosures.

 Key Features:

  • Stitched surround and paper cone assembly
  • Rubber Motor boot with DC Logo
  • Polypropylene dust cover with DC logo
  • Heavy duty interweaved tinsel lead wire sewn to the spider
  • Stamped Steel black frame
  • FEA analyzed and optimized motor assembly - Fully CNC machined
  • Rubber mounting gasket
  • Rubber Motor Boot
  • Chrome spring loaded push terminals
  • 2.0” voice coil

Click HERE to get a Subwoofer Box



T/S Parameters

M3 Level 1 Subwoofers 10" 12"
Mounting Depth 6" 6.5"
Mounting Hole Diameter 9.3" 11.2"
Outside Driver Diameter 11" 12.5"
VC Diameter 2.0" 2.0"
Displacement .12 ft .14ft
Power Handling rms/peak 300/600 300/600
Ohm Options d2/d4 d2/d4
Sd 324 cm 481 cm
Vas 17.1 L 47.7 L
Cms 0.12 Mm/n 0.12 Mm/n
Mms 146.8 g 168 g
Fs 37 Hz 32.6 Hz
Bl 23.2 N/A 23.2 N/A
Re 8 Ohm 8 Ohm
Le 3.88 mH 2.79 mH
Qms 3.15
 2.52
Qes 0.52
 0.51
Qts 0.45 0.43
Xmax 19mm 19mm
Ref SPL @1 watt 84.2 db 86.9 db
Suggest Sealed Box .5 ft .75 ft
Suggested Ported Box 1.0 ft 1.25 ft
