DS18
PRO 8" Slim Neodymium Mid-Range Loudspeaker with Bullet | 500W 4-Ohm
PRO 8" Slim Neodymium Mid-Range Loudspeaker with Bullet | 500W 4-Ohm
Couldn't load pickup availability
PRO 8" Slim Neodymium Mid-Range Loudspeaker with Bullet | 500W 4-Ohm
Sold by AudioSellerz.com
The DS18 PRO-NEO8SLIM is an 8" mid-range loudspeaker from the DS18 PRO line with a 4 ohm design. Swapping in better speakers is one of the most noticeable upgrades you can make to any system.
DS18 Product Details
DS18 PRO-NEO8SLIM PRO 8" Shallow Neodymium Mid-Range Loudspeaker with Bullet 500 Watts 4-Ohm
|
DS18 PRO-NEO8SLIM amassed a wealth of experience in manufacturing the most elegant neodymium midranges for those seeking simple perfection. Neodymium magnets provide a higher magnetic flux density in the air gap, which generates a much greater action force in the voice coil. For this reason, Neo magnets have the strongest permanent magnets of all the commercially available speakers. Ranging in sizes, mounting depths, and frequency responses, we have more than 10 different models of Neo mids to accommodate any build. Highlights
|
Technical Details
| Model: | PRO-NEO8SLIM |
| Type: | Shallow Midrange Loudspeaker with Bullet |
| Size: | 8" |
| RMS Power: | 250W |
| MAX Power: | 500W |
| Frequency Response: | 120Hz - 12KHz |
| Impedance: | 4 Ohms |
| Sensitivity: | 95dB |
| Materials | |
| Surround: | Cloth Edge |
| Frame: | Black Aluminum Basket |
| Cone: | Non-Pressed Paper Cone |
| Magnet: | Neodymium |
| Voice Coil Wire: | KCCAW |
| Diameters | |
| Voice Coil Size: | 2" |
| Magnet Size: | 4 oz. |
| Mounting Depth: | 2.22" (56.6mm) |
| Cut-Out Dimensions: | 7.20" (183mm) |
| Net Weight: | 1.7kg |
Setup Tips From Audio Sellerz
- Match the amplifier's RMS power per channel to the speaker's RMS rating at its impedance, then set the gain carefully instead of turning it all the way up.
- Use a high-pass filter so deep bass goes to the subwoofer. The speakers will play louder and cleaner without it.
- Pro audio mids work best with a proper crossover or DSP so each driver only plays the range it was built for.
