DC Audio
NEO 3.0 Subwoofers
NEO 3.0 Subwoofers
Couldn't load pickup availability
NEO 3.0 Subwoofers
Sold by AudioSellerz.com
Use the DC Audio NEO 3.0 Subwoofers when researching DC Audio subs for a daily-driver, custom enclosure, or higher-output bass build. The exact product details below should be checked against the amplifier, final ohm load, available box space, enclosure design, vehicle, and electrical support before ordering.
A subwoofer performs within a complete system. Confirm voice-coil configuration, final ohm load, amplifier match, enclosure volume and tuning, mounting dimensions, speaker wire, power wire, fuse protection, and voltage support using the product specifications supplied below.
Original Product Details
**HAND BUILT IN THE USA**
BUILD TIME 7-14 DAYS
Neo 3.0 Subwoofer Line
2024 Cone Change : Now Comes Stock with TR Cone / Surround
2200 Watts RMS 4400 Watts Peak
Available in 15 and 18" Models
Subwoofer Description
The NEO 3.0 is a subwoofer built for SPL!! If you're looking for a SPL Championship proven subwoofer, here you go.
Custom Coil and Spider Configurations to get every tenth of a db out of it available.
Key Features
- FULL NEO Columns (not partials set ontop of steel pillars)
- Extremely rigid TR paper cone assembly
- Multilayered polymer foam surround
- Polypropylene dust cover with DC logo
- 8” OD semi cup progressive roll spiders
- Dual extra heavy duty interweaved tinsel lead wire
- Cast aluminum black frame
- FEA analyzed and optimized motor assembly – Fully CNC machined
- Rubber mounting gasket
- 4 AWG Chrome spring loaded push terminals
- 3" 8 layer hi-temp flat wound aluminum voice coil
Click HERE to get a Subwoofer Box
T/S Parameters
| 15" | 18" | |
|---|---|---|
| Mounting Depth | 9" | 11" |
| Mounting Hole Diameter | 14" | 16.75" |
| Outside Driver Diameter | 15.7" | 18.5" |
| VC Diameter | 3.0" | 3.0" |
| Displacement | .23ft | .26ft |
| Power Handling rms/peak | 2200/4400 | 2200/4400 |
| Ohm Options | d.7/d1/d2/d4 | d.7/d1/d2/d4 |
| Sd | 791 cm | 1159 cm |
| Vas | L | L |
| Cms | Mm/n | Mm/n |
| Mms | g | g |
| Fs | Hz | Hz |
| Bl | N/A | N/A |
| Re | Ohm | Ohm |
| Le | mH | mH |
| Qms | ||
| Qes | ||
| Qts | ||
| Xmax | 23mm | 23mm |
| Ref SPL @1 watt | db | db |
| Suggest Sealed Box | ft | ft |
| Suggested Ported Box | 3.0 ft | 5.5 ft |
Plan the DC Audio Subwoofer, Amplifier, and Enclosure Together
Shop more DC Audio subwoofers or return to the main DC Audio collection at Audio Sellerz. When the enclosure is part of the next step, compare DC Audio subwoofer boxes and the wider car audio subwoofer box collection.
Use the subwoofer specifications guide to understand common subwoofer terms, the subwoofer wiring-diagram and ohm-load guide to plan final impedance, and the complete car audio bass setup guide to match the sub, amplifier, box, wire, fusing, and electrical support.
Confirm the Exact Product Before Ordering
Use the product title and selected variant as the starting point, then review every original specification, compatibility note, dimension, quantity, build-time notice, shipping limitation, and other condition provided above. Confirm the equipment and installation requirements before placing the order.
