DS18 PRO-TW320.8 4" Super Tweeter with Bullet 8 Ohms (Single)

DS18 PRO-TW320.8 4" Super Tweeter with Bullet 8 Ohms (Single)

Sold by AudioSellerz.com

SKU: PRO-TW320.8

DS18 PRO-TW320.8 4" Super Tweeter with Bullet 8 Ohms (Single) is a DS18 tweeter upgrade from DS18 built for stronger high-frequency output, louder vocals, brighter detail, and balanced mids and highs systems. This description helps shoppers looking for DS18 tweeters, car audio tweeters, super tweeters, high frequency speakers, loud mids and highs understand where it fits in a real audio system.

Audio Sellerz focuses on the full build, not just one part. Match this DS18 product with the right vehicle, mounting space, amplifier power, wiring, fuse protection, enclosure needs, and electrical support so the system plays cleaner, louder, and more reliably.

Audio Sellerz System Match Notes

• Use the correct crossover points, amplifier power, and tuning so the highs stay loud without getting harsh.
• For amplified audio systems, make sure the power wire, ground, fuse protection, and voltage support match the equipment.
• If you are building a complete DS18 setup, plan the speakers, subwoofers, amplifiers, wiring, and electrical support together before ordering.

DS18 PRO-TW320.8 4" Super Tweeter with Bullet 8 Ohms (Single)

The PRO-TW 320.8 has all the characteristics of our best-selling counterpart except now we offer them in 8-ohm for even more possibilities of connections in your vehicle. This high intensity super tweeter has a sensitivity of 107 dB so it does not require full RMS power to get very loud. These super-tweeters handle an RMS of 250w and a maximum power of 500w. With such a high frequency range of 1.6KHz to 20KHz, you will be sure not to miss out on every hiss of a high hat and every cymbal crash. These die cast aluminum super tweeters house a massive 1.5-inch aluminum diaphragm and are easily replaceable with an allen key and 3 minutes of your time, ensuring fast and easy repair even on the go!

Highlights

• Extremely loud design that will let you pick your tweeter volume from subtle to extreme by making small adjustments to your amplifier.
• High Power super Tweeter bullet design brings extreme high range volume that can be heard for great distances and fill out your frequency range effortlessly.
• Designed to be repaired quickly and easily with our drop in voice coil kits that install in less than 5 minutes.

Technical Details

Download PRO-TW320.8 Product Manual

Model:	PRO-TW320.8
Type:	Super Bullet Tweeter
Peak Power Handling	480 Watts
Program Power Handling	240 Watts
AES Power Handling	120 Watts
Voice Coil Diameter:	1.5"
Diaphragm Material:	Aluminum
Sensitivity:	107dB
Impedance:	8 Ohms
Frequency Response:	1.6KHz - 20KHz
Package Quantity:	1
Magnet Weight	14.3 Oz
Replacement Diaphragm:	PRO-TW320VC
Magnet	Ferrite
Measurements
Overall Depth	2.57"
Mounting Depth	2.22"
Overall Width	4.01"
Cutout Diameter	3.54"
