DS18 PRO-GM8 8" Mid-Range Loudspeaker 580 Watts 8-Ohm
DS18 PRO-GM8 8" Mid-Range Loudspeaker 580 Watts 8-Ohm
Couldn't load pickup availability
DS18 PRO-GM8 8" Mid-Range Loudspeaker 580 Watts 8-Ohm
Sold by AudioSellerz.com
The DS18 PRO-GM8 is an 8" mid-range loudspeaker from the DS18 PRO line with an 8 ohm design. Swapping in better speakers is one of the most noticeable upgrades you can make to any system.
DS18 Product Details
|
During the focused R&D period of perfecting the PRO-EXL line, DS18 identified the opportunity to spawn off another line since there was a division amongst competition audiophiles and concert/"voceteo" audiophiles. Therefore, DS18 created the PRO-GM audio line, which features a wide variety of midranges the produce concert-like sounds that will knock the wind out of you. A midrange driver is called upon to handle the most significant part of the audible sound spectrum, the region where the most fundamentals emitted by musical instruments and, most importantly, the human voice, lie. This region contains sounds which are the most familiar to the human ear, and where discrepancies from faithful reproduction are most easily observed. It is therefore paramount that a midrange driver of good quality be capable of low-distortion reproduction. |
Highlights
- DS18's highly popular series of High Powered pro audio.
- Great DS18 design of high durability parts including strong ferrite magnet, pressed paper cone, and CCA voice coils to get you maximum loudness with great sound quality.
- These mids come with a solid cone design and are pure midrange speakers and will be greatly complemented with a not included tweeter.
Technical details
| Model: | PRO-GM8 |
| Type: | Midrange Loudspeaker |
| Size: | 8" |
| RMS Power: | 190W |
| MAX Power: | 580W |
| Frequency Response: | 90Hz-10KHz |
| Impedance: | 8 Ohms |
| Sensitivity: | 93 dB |
| Materials | |
| Surround: | Cloth |
| Basket: | Steel |
| Cone: | Paper |
| Magnet: | Ferrite |
| Voice Coil Wire: | Kapton |
|
Measurements |
|
| Voice coil size: | 1.5" |
| Magnet Weight: | 30 oz. |
| Mounting Depth: | 3.22" / 82mm |
| Cut-Out Dimension: | 7.2" / 183mm |
Setup Tips From Audio Sellerz
- Match the amplifier's RMS power per channel to the speaker's RMS rating at its impedance, then set the gain carefully instead of turning it all the way up.
- Use a high-pass filter so deep bass goes to the subwoofer. The speakers will play louder and cleaner without it.
- Pro audio mids work best with a proper crossover or DSP so each driver only plays the range it was built for.
