DS18 PRO-GM8.4B 8" Mid-Range Loudspeaker with Bullet 580 Watts 4-Ohm
DS18 PRO-GM8.4B 8" Mid-Range Loudspeaker with Bullet 580 Watts 4-Ohm
Couldn't load pickup availability
DS18 PRO-GM8.4B 8" Mid-Range Loudspeaker with Bullet 580 Watts 4-Ohm
Sold by AudioSellerz.com
The DS18 PRO-GM8.4B is an 8" mid-range loudspeaker from the DS18 PRO line with a 4 ohm design. Coaxials and loudspeakers like this are where most systems start, because the speakers decide how clear the whole build sounds.
DS18 Product Details
The PRO GM series was brought in to bring loud high quality pro audio to the entry level user. This pro audio is leaps ahead of the competition in quality and over all loudness. The PRO GM series is offered in many different styles and variations to fit all your system’s needs.
Highlights
-
DS18's highly popular series of High Powered pro audio.
-
Great DS18 design of high durability parts including strong ferrite magnet, pressed paper cone, and CCA voice coils to get you maximum loudness with great sound quality.
-
BM stands for BULLET! This includes a resonator (tweeter) with red bullet design to give the speaker a much higher range of frequencies.
Technical Details
| Model: | PRO-GM8.4B |
| Type: | Midrange Loudspeaker |
| Size: | 8" |
| RMS Power: | 190W |
| MAX Power: | 580W |
| Frequency Response: | 90Hz-10KHz |
| Impedance: | 4 Ohms |
| Sensitivity: | 96dB |
| Materials | |
| Surround: | Cloth Surround |
| Frame: | Black Stamp Steel Basket |
| Cone: | Black Paper Woofer Cone |
| Magnet: | Ferrite |
| Voice Coil Wire: | Kapton |
| Measurements | |
| Voice coil size: | 1.5" |
| Magnet Weight: | 30 oz. |
| Mounting Depth: | 3.11" (86mm) |
| Cut-Out Dimension: | 7.16" (182mm) |
Setup Tips From Audio Sellerz
- Match the amplifier's RMS power per channel to the speaker's RMS rating at its impedance, then set the gain carefully instead of turning it all the way up.
- Use a high-pass filter so deep bass goes to the subwoofer. The speakers will play louder and cleaner without it.
- Pro audio mids work best with a proper crossover or DSP so each driver only plays the range it was built for.
