B2 Audio 15" Subwoofer 1000W RMS 3" Voice Coil Dual 2-Ohm RIOT

B2 Audio 15" Subwoofer 1000W RMS 3" Voice Coil Dual 2-Ohm RIOT

Sold by AudioSellerz.com

The B2 Audio 15" Subwoofer 1000W RMS 3" Voice Coil Dual 2-Ohm RIOT is a car audio subwoofer from B2 Audio, sold by Audio Sellerz. This page keeps the supplied product details and specifications intact so you can review the actual model information before ordering. Use the product details below to confirm power, impedance, dimensions, fitment, included parts, and other specifications that apply to this exact B2 Audio model.

B2 Audio Product Details & Specifications

• 1000W RMS PERFORMANCE FOR SERIOUS BASS - Delivers 1000 Watts RMS and 3000 Watts Peak power handling with a high-efficiency motor designed for powerful daily listening and high-output SPL systems without sacrificing sound quality.
• DUAL 2 OHM VOICE COILS FOR FLEXIBLE WIRING - Dual 2-ohm configuration allows multiple wiring options, including a 1-ohm or 4-ohm final load, making it easy to match a wide range of mono amplifiers and custom car audio installations.
• 3" HIGH-TEMPERATURE VOICE COIL & 18MM XMAX - Features a large 3-inch high-temp voice coil and 18mm one-way XMAX for excellent thermal handling, deep excursion, low-frequency extension, and reliable performance under demanding conditions.
• DESIGNED FOR SEALED OR PORTED ENCLOSURES - Engineered to perform exceptionally well in sealed, ported, or 4th-order bandpass enclosures, allowing you to choose the enclosure style that best fits your desired balance of sound quality and output.

B2 Audio 15" 1000W RMS 3" Voice Coil Dual 2-Ohm Riot Subwoofer

This listing includes:

• (1) B2 Audio Riot 15" Subwoofer

When you're ready to step up to serious bass, the RIOT15-D2 delivers. This 15" sub features a beefy 3" coil, high-excursion 18mm XMAX, and optimized motor structure for full control at high output. With 1000W RMS handling and flexible 2-ohm dual voice coils, it's perfect for sealed, ported, or even bandpass enclosures.

Get ready for chest-thumping lows with a smooth curve that's designed to shake mirrors and hold power all day long.

Features:

• 1000W RMS / 3000W Peak Power - Capable and reliable for both daily and demo setups


• Dual 2 Ohm Voice Coil - Flexible wiring for 1 Ohm or 4 Ohm loads


• 3" High-Temp Voice Coil - Built to handle heat and SPL abuse


• 18mm XMAX - Deep excursion for low, controlled bass


• Sealed, Ported, or Bandpass Friendly - Tuned to perform in a variety of enclosures

Specifications:

• Sensitivity: 86 dB (1w/1m)


• Nominal Impedance: Dual 2 Ohm


• Power Handling: 1000W RMS / 3000W Peak


• Voice Coil Diameter: 3"


• XMAX one way (mm): 18


• Magnet: 240 oz


• VAS: 60.1 L


• FS: 30 Hz


• QES: 0.8


• QMS: 7.5


• QTS: 0.72


• CMS: 70 um/N


• MMS: 379 g


• BL^2/RE: 106.8


• Displacement: 7.4 L / 0.26 cu.ft


• Mounting Depth: 8.11" (206mm)

Recommended Enclosures

• Sealed: 63.5 L / 2.24 cu. ft, Qtc 0.72, Fb 42.8 Hz


• Ported Compact: 80 L / 2.83 cu. ft, Port area 20 sq. in L: 12.8", FB: 35 Hz


• Ported: 141 L / 5 cu. ft, Port area 20 sq. in, L: 9.1", FB: 30 Hz


• BP 4th: 3:1 Ratio

Dimensions

• Overall Diameter: 15.35" (390mm)


• Mounting Diameter: 14.76" (375mm)


• Cutout Diameter: 13.78" (350mm)


• Magnet Width: 7.40" (188mm)


• Mounting Depth: 8.11" (206mm)


• Overall Depth: 8.78" (223mm)
