DS18
PRO 10" Neodymium Mid-Bass Loudspeaker 500 Watts Rms 4-Ohm
PRO 10" Neodymium Mid-Bass Loudspeaker 500 Watts Rms 4-Ohm
Couldn't load pickup availability
PRO 10" Neodymium Mid-Bass Loudspeaker 500 Watts Rms 4-Ohm
Sold by AudioSellerz.com
The DS18 PRO-NEO10R is a 10" mid-bass loudspeaker from the DS18 PRO line rated at 500W RMS with a 4 ohm design. Coaxials and loudspeakers like this are where most systems start, because the speakers decide how clear the whole build sounds.
DS18 Product Details
DS18 PRO-NEO10R 10" Neodymium Mid-Range Loudspeaker 1000 Watts 4-Ohm
DS18 amassed a wealth of experience in manufacturing the most elegant neodymium midranges for those seeking simple perfection. Neodymium magnets provide a higher magnetic flux density in the air gap, which generates a much greater action force in the voice coil. For this reason, Neo magnets have the strongest permanent magnets of all the commercially available speakers. Ranging in sizes, mounting depths, and frequency responses, we have more than 10 different models of Neo midranges to accommodate any build.
Highlights
- High powered aluminum voice coil backed by an intense neodymium rings magnet for more volume at the highest efficiency on the market.
- Beautiful DS18 design including a DS18 Tooled aluminum brushed accented basket and high quality terminals.
- Solid cone design that slays the midrange but is best accompanied by a pro audio super tweeter.
Technical Details
| Model: | PRO-NEO10R |
| Type: | Midrange Loudspeaker |
| Size: | 10" |
| RMS Power: | 500W |
| MAX Power: | 1000W |
| Frequency Response: | 60Hz - 11KHz |
| Impedance: | 4 Ohms |
| Sensitivity: | 98dB |
| Materials | |
| Surround: | Cloth Edge |
| Frame: | Red Aluminum Basket |
| Cone: | Non-Pressed Paper Cone |
| Magnet: | Neodymium Rings |
| Voice Coil Wire: | TICCAW |
| Measurements | |
| Voice Coil Size: | 2.5" |
| Magnet Weight: | 18 oz |
| Mounting Depth: | 4.28" (109mm) |
| Cut-Out Dimensions: | 9.02" (229mm) |
| Net Weight: | 3.65 Kg |
Setup Tips From Audio Sellerz
- Power it with an amplifier channel rated close to its 500W RMS at 4 ohms, then set the gain carefully instead of turning it all the way up.
- Use a high-pass filter so deep bass goes to the subwoofer. The speakers will play louder and cleaner without it.
- Pro audio mids work best with a proper crossover or DSP so each driver only plays the range it was built for.
