SoundQubed HDS2.208 8" Subwoofer 600W RMS D2 or D4

$169.95 USD

Sale Sold out

Shipping calculated at checkout.

Ohm Load D2 D4

SoundQubed HDS2.208 8" Subwoofer 600W RMS D2 or D4

Sold by AudioSellerz.com

The SoundQubed HDS2.208 8" Subwoofer 600W RMS D2 or D4 is a SoundQubed HDS2.208 8-inch car audio subwoofer for a properly matched car audio bass system. The product title lists 600 watts RMS. It is offered in Dual 2 Ohm and Dual 4 Ohm voice-coil options according to the title.

Use this page to compare the exact model, size, RMS rating, voice-coil options, enclosure requirements, wiring plan, and electrical support before ordering. The original specifications and product details remain below.

Original Product Details and Specifications

If you want an 8" subwoofer that fits easier while still giving you real bass output, the SoundQubed HDS2.208 is a strong choice for daily-driver builds that need clean low-end performance without taking up a ton of space. This model is part of the HDS2 series, which was built as an affordable option for everyday car audio systems while still improving on the earlier series in build quality, sound quality, heat dispersion, and frequency response.

The HDS2.208 is rated at 600 watts RMS and 1200 watts peak power, with dual 2 ohm and dual 4 ohm options to give you more flexibility when wiring your system. It uses a 2.5" voice coil, 100 oz magnet, and 36 mm coil length, which helps make it a solid fit for customers shopping for an 8" subwoofer that can handle real amplifier power in a compact setup.

This sub also gives you practical box options depending on the kind of bass response you want. Recommended sealed enclosure volume is .35 to .75 cubic feet, while recommended ported enclosure volume is .75 to 1.25 cubic feet. Mounting depth is 5.5" and cutout is 7.5", which helps when planning the enclosure and making sure the sub fits your install correctly.

If you are looking for a SoundQubed 8" subwoofer, HDS2.208 sub, compact 600 watt RMS subwoofer, or a dual voice coil 8" woofer for a daily system, this one checks the right boxes. It gives you solid power handling, flexible impedance options, and enclosure recommendations that make it easier to build around your goals.

Specifications

Specification: Details
Brand: SoundQubed
Model: HDS2.208
Speaker Size: 8"
RMS Power Handling: 600 watts
Peak Power Handling: 1200 watts
Impedance Options: D2 or D4
Magnet Weight: 100 oz
Voice Coil Diameter: 2.5"
Coil Length: 36 mm
Fs: 44.41 Hz
Zmax: 38.77 ohms
Qms: 4.465
Mounting Depth: 5.5"
Circle Cutout: 7.5"
Recommended Sealed Enclosure: .35 to .75 cubic feet
Recommended Ported Enclosure: .75 to 1.25 cubic feet

Match This SoundQubed Subwoofer to the Amplifier and Enclosure

A subwoofer money page must connect the woofer to the rest of the bass system. Match the verified RMS power handling and voice-coil configuration to a stable amplifier load. Then confirm the enclosure type, net air space, tuning, port area, mounting depth, cutout, subwoofer displacement, available vehicle space, speaker wire, and electrical support from the exact specifications.

Shop Related SoundQubed Bass-System Products

Compare more SoundQubed subwoofers, browse monoblock car audio amplifiers, and shop subwoofer boxes and enclosures for the rest of the bass-system plan.

Helpful Subwoofer Guides

Use the subwoofer wiring diagrams and final ohm-load guide before choosing a voice-coil option. Read the subwoofer enclosure guide before selecting or building a box, and use the complete car audio bass setup guide to match the subwoofer, amplifier, enclosure, wiring, fusing, battery, and alternator.

The subwoofer specifications guide explains common woofer ratings, while the amplifier gain guide for subwoofers helps protect the system from poor setup and clipping.

Shop SoundQubed at Audio Sellerz

Browse the complete SoundQubed car audio collection at Audio Sellerz for SoundQubed subwoofers, amplifiers, speakers, tweeters, wiring, deadener, and system accessories. Read why Audio Sellerz sells and supports SoundQubed to learn more about the brand relationship and the product categories we carry.

Frequently Asked Questions About SoundQubed HDS2.208 8" Subwoofer 600W RMS D2 or D4

What amplifier should I use with this SoundQubed subwoofer?

Use the product's verified RMS power handling, voice-coil configuration, number of subwoofers, final wired impedance, and the amplifier's continuous output at that impedance. Do not match from peak or maximum power alone.

Which voice-coil option should I choose?

The title lists Dual 2 Ohm and Dual 4 Ohm options. Choose the version that produces a safe final load for the amplifier after accounting for the number of subwoofers and the planned series or parallel wiring.

What enclosure should I use?

Use the exact enclosure recommendations, displacement, mounting depth, and cutout information listed for this model. The best box also depends on the vehicle, available space, music, and desired output.
