The DS18 EXL-X12.2D is a 12" subwoofer from the DS18 EXL line rated at 1250W RMS with a 2 ohm dual voice coil design. This is the part of the system that does the heavy lifting down low.
DS18 Product Details
DS18 EXL-X12.2D 12" Car Subwoofer 2500 Watts 2-Ohm DVC
EXL X (Extremely loud) competition grade subwoofers features DS18 private red aluminum basket, Fiber Glass dust cap, 2.57" voice coils and 2500 watts of power, with the combination of modern technologies and unique engineering solutions this subwoofer is the evidence of DS18 technological and methodical dominance, EXL X is the best choice to enter the bass head world in the lanes or to play daily music.
Highlights
- Premier DS18 Subwoofer line brings great bass without being super power hungry and looks amazing.
- High strength rubber surround will hold with great ease while pushing out loud and clean bass.
- Amazing looks including DS18 red painted basket with DS18 stamped protective motor boot.
- Designed for sealed / ported boxes and will produce amazing bass in all vehicles.
Technical Details
| Model: | EXL-X12.2D |
| Type: | Subwoofer |
| Size: | 12" |
| RMS Power: | 1250W |
| MAX Power: | 2500W |
| Impedance: | 2 + 2 ohms |
| Voice Coil Size: | 2.57" |
| Magnet: | Ferrite |
| Magnet Size: | 2 x 105 oz |
| Frequency Response: | 30Hz - 1.7KHz |
| Materials | |
| Frame: | DS18 Private Red Aluminum |
| Cone: | Paper |
| Surround: | Foam Edge |
| Dust Cap: | Glass Fiber |
| Voice Coil Former Material: | Black Aluminum |
| Measurements | |
| Mounting Cut-Out: | 11.1" (282mm) |
| Mounting Depth: | 7" (180mm) |
| Overall Diameter: | 12.6" (321mm) |
| Net Weight: | 15kg |
Box Info
Setup Tips From Audio Sellerz
- Wire the sub to a final impedance your amp is stable at. The listing rates this one at 2 ohm per coil.
- Use an enclosure built to the manufacturer recommendation. The box makes a big difference in output and sound.
- Break the sub in at moderate volume and set the amp gain correctly before playing it hard.
