Sky High Car Audio SH-DTN1N Neodymium Horn Driver – 8 Ohm
Sky High Car Audio SH-DTN1N Neodymium Horn Driver – 8 Ohm
Couldn't load pickup availability
Sky High Car Audio Neodymium Horn Driver SH-DTN1N
Sold by AudioSellerz.com
The Sky High Car Audio SH-DTN1N Neodymium Horn Driver is built for pro audio style car systems, motorcycle front stages, and demo vehicles that need loud, clean high frequencies that can keep up with strong mids and heavy bass. Using a compact neodymium motor, phenolic diaphragm, and matched horn, this driver delivers high output and clarity from 1.5 kHz up to 18 kHz, making it perfect for door panels, pods, pro audio doors, and show builds.
With a nominal impedance of 8 ohm and AES power handling of 60W (120W program / 240W peak), the SH-DTN1N is designed to play loud while staying controlled when crossed properly. Sensitivity is rated at 108 dB (1W/1m with horn), meaning it gets extremely loud on realistic amplifier power and is ideal for use in efficient, high-output front stage designs.
The driver uses a 1” (25.4 mm) voice coil wound on a Kanton former with CCA winding for a strong balance of performance and reliability. A phenolic diaphragm provides a smooth, durable high-frequency response, especially useful in harsh mobile environments where temperature and volume levels can get intense. The neodymium magnet keeps the motor lightweight and compact while still delivering strong magnetic force.
The included horn uses a 2.7” x 4.7” (70 x 120 mm) nominal diameter with a 1” throat, and offers 45° x 30° sound coverage. The horn body is made from ABS with a black finish, giving a clean, pro-style look when installed in door panels, A-pillars, pods, or custom baffles.
Compact overall measurements and shallow mounting depth make this horn driver easy to incorporate into tight builds:
- Overall Diameter: 4.72” x 2.75” (120 x 70 mm)
- Overall Depth: 3.12” (79.5 mm)
- Mounting Depth: 2.48” (63 mm)
- Mounting Hole Pattern: 2.75” x 2.3” (69.8 x 58.4 mm)
If you’re building a pro audio front stage, loud motorcycle system, or demo car and need a high efficiency 8 ohm horn driver with a neodymium motor, the Sky High Car Audio SH-DTN1N is a strong, compact option that delivers serious output with a clean, professional look.
Key Features – SH-DTN1N Neodymium Horn Driver
- Nominal Impedance: 8 ohm
- AES Power Handling: 60W
- Program Power Handling: 120W
- Peak Power Handling: 240W
- Sensitivity (1W/1m with horn): 108 dB
- Frequency Response: 1.5 kHz – 18 kHz
- Recommended Low Pass Crossover: 2 kHz
- Configuration: Single driver (sold individually)
Motor & Diaphragm
- Voice Coil Diameter: 1” / 25.4 mm
- Former Material: Kanton
- Winding Material: CCA
- Diaphragm Material: Phenolic
- Magnet Material: Neodymium
- Magnet Size: 0.96” x 0.19” (24.5 x 5 mm)
- Motor Diameter: 2.2” / 57.2 mm
- Body Material: Aluminum
Horn Specs
- Nominal Diameter: 2.7” x 4.7” / 70 x 120 mm
- Throat Diameter: 1” / 25.4 mm
- Sound Coverage: 45° x 30°
- Body Material: ABS
- Color/Finish: Black
