DC Audio NEO CF 10" Full Range Pro Audio

$184.99 USD

~~$169.99 USD~~ $184.99 USD

Sale Sold out

Shipping calculated at checkout.

Style Pro NEO 10 SVC 4ohm Pro NEO 10 SVC 8ohm

DC Audio NEO CF 10" Full Range Pro Audio

Sold by AudioSellerz.com

Use the DC Audio NEO CF 10" Full Range Pro Audio when comparing DC Audio speakers for a factory-location upgrade, custom door, speaker pod, or amplified front-stage system where the published specifications fit the application. Review every original detail below before matching the speaker with an amplifier and crossover settings.

Relevant searches may include DC Audio NEO CF 10" Full Range Pro Audio, DC Audio speakers, DC Audio pro audio speakers, car audio mids and highs, or a full-range pro audio speaker. The right result comes from matching the speaker to the amplifier channels, crossover settings, available mounting area, and the rest of the system—not from diameter alone.

Original Product Details

DC Audio 10" Pro Audio Speaker

Power Rating 400 watts RMS 800 watt Program

Frequency Response: 55hz-3khz

3" Aluminum Voice Coil

4 or 8 ohms impedance options

Sensitivity 1w/1m 100db

Cut Out 9.25"

Outside Diameter 10.25”

Mounting Depth 4.95

Cast Frame

Carbon Cone and Dust Cap

Magnet Material: Neodymium

Sold in Individuals

T/S Parameters

RE: 6.8

BL: 16.84

MMS: 50.51

QTS: 0.37

QMS: 4.28

QES: 0.4126

CMS: 0.1706

VAS: 25.58

FS: 54.21

SD: 0.0346

** These Speakers are for High Output Applications and 99% of the time require custom installations or modifications to fit the Massive Motor and Frame used for the Pro Audio Line up
