B2 Audio Bolt On Compression Driver RAGE CDR-44 200W RMS 4 Ohm

B2 Audio Bolt On Compression Driver RAGE CDR-44 200W RMS 4 Ohm

Sold by AudioSellerz.com

The B2 Audio Bolt On Compression Driver RAGE CDR-44 200W RMS 4 Ohm is a high-frequency car audio component from B2 Audio, sold by Audio Sellerz. This page keeps the supplied product details and specifications intact so you can review the actual model information before ordering. Use the product details below to confirm power, impedance, dimensions, fitment, included parts, and other specifications that apply to this exact B2 Audio model.

B2 Audio Product Details & Specifications

• High-Power 1.75" Compression Driver: Engineered for serious output with a large 1.75" titanium diaphragm and powerful ferrite motor, delivering crystal-clear highs even at extreme volume.
• 200W RMS / 400W Max Power Handling: Built to handle heavy daily use, this driver offers massive power capability for pro-audio door builds, pods, arrays, and high-SPL systems.
• Wide Frequency Range: 1.5 kHz–20 kHz Produces smooth, detailed upper midrange and sparkling highs with excellent projection and clarity across a wide bandwidth.
• Bolt-On 4-Bolt Mounting Pattern: Compatible with standard M5 bolt-on horns (including the B2-RAGECDH-44), ensuring a secure fit, stronger performance, and optimal dispersion.
• High Efficiency & Precision Control: CCA-wound voice coil and 106 dB sensitivity deliver clean detail, strong efficiency, and stable performance under demanding audio conditions.

B2 Audio 200W RMS 4 Ohm 1.75" VC 1" Throat Bolt On Compression Driver RAGE CDR-44

This Listing includes:

• (1) B2-RAGECDR-44 1.75" Driver

Meet the next-level heavy-hitter in the RAGE high-frequency lineup. The B2 Audio RAGECDR-44 is a full-size, bolt-on compression driver built for extreme output, incredible clarity, and serious durability. Compared to the shallow CDR and CDR-V2 models, the CDR-44 steps into a higher class — offering a larger 1.75" titanium diaphragm, more robust ferrite motor, and far greater power handling for demanding pro-audio-style builds.

Engineered to deliver crisp, controlled highs from 1.5 kHz up to a piercing 20 kHz, this driver thrives in setups where volume, projection, and detail are non-negotiable. The ferrite motor provides raw strength and stability, while the CCAW coil ensures efficient heat dissipation under heavy load. Whether you're running large door panels, pro audio pods, or multi-driver high-output arrays, the RAGECDR-44 provides the authority and precision needed to dominate the upper frequency spectrum.

Pair it with the B2-RAGECDH-44 bolt-on horns (sold separately) for optimized dispersion and maximum impact.

Features

• High-Output Design – Built for extreme volume and clarity with a powerful ferrite motor.


• Titanium Diaphragm – Delivers crisp, detailed highs with long-term durability.


• Large 1.75" Voice Coil – Handles serious power while maintaining precision.


• Bolt-On Mounting – Compatible with 4-bolt horns, including the upcoming B2-RAGECDH-44.


• Efficient CCAW Winding – Improved heat dissipation for cleaner performance at high output.


• Wide Frequency Range – Plays smoothly from 1.5 kHz to 20 kHz with excellent projection.


• Pro-Audio Grade Construction – Ideal for large mids/highs arrays, door builds, and open-air systems.

Specifications:

• Throat Diameter: 1" / 28.0 mm


• Max Power: 400 Watts


• RMS Power Impedance: 200 Watts


• Impedance: 4-Ohms


• Frequency Response: 1.5 Khz-20 Khz


• Capacitors are not included, we recommend using 33 F Capacitors for best performance (~1,200 Hz cutoff at 4 Ohm)


• Sensitivity(1w/1m): 106 dB


• Voice Coil Diameter: 44.4mm/1.75"


• Winding Material: CCAW


• Magnet: Ferrite


• Diaphragm type: Titanium

Dimensions:

• Overall Diameter: 4.53"


• Bolt Circle Diameter: 4 holes/75mm apart/M5 bolts


• Depth: 2.07"
