DS18
2" Throat Bolt on Driver 320 Watts 2" Phenolic Vc 8-Ohm
2" Throat Bolt on Driver 320 Watts 2" Phenolic Vc 8-Ohm
Couldn't load pickup availability
2" Throat Bolt on Driver 320 Watts 2" Phenolic Vc 8-Ohm
Sold by AudioSellerz.com
The DS18 PRO-DPL1PH is a 2" driver from the DS18 PRO line with an 8 ohm design. Pro audio drivers and horns are made for high output and efficiency, the kind of top end that stays loud and clear with the windows down.
DS18 Product Details
DS18 PRO-DPL1PH 2" Throat Bolt On Compression Driver 2" Phenolic VC 640 Watts 8 ohm
Drivers are known for their extreme loudness all while maintaining the highest efficiency and decibel to wattage ratio. Ferrite is definitely a great motor structure you want to go with for the absolute loudest ear piercing high range frequencies. This ferrite driver is compatible with 4 bolt horns (throat) of all sizes. This will be an amazing addition to any system that needs super loud highs.
This driver comes with a massive 2 inch titanium voice coil that takes 160 AES and 640 Peak power for extreme decibel production backed with a high efficiency motor.
Highlights
- Ferrite motor structure that provides great motor force and loudness.
- High strength phenolic voice coil taking 160 AES watts and 640 Peak watts.
- Intense high frequency volume without sacrificing sound quality.
- Compatible with all DS18 4 bolt throats giving a huge variety of mounting depths
Technical Details
| SPECIFICATIONS | |
| Throat Diameter | 2" / 50.8 mm |
| Installation Type | Bolt on |
| Nominal Impedance | 8 Ohms |
| AES Power Handling | 160W |
| Program Power Handling | 320W |
| Peak Power Handling | 640W |
| Sensitivity (1w/1m) | 109dB |
| Frequency Response | 500Hz-18KHz |
| Recommended Hi Pass Crossover | 800 Hz |
| MOTOR | |
| Voice Coil Diameter | 2.03" / 51.5mm |
| VC Former Material | Kapton |
| Winding Material | CCA |
| Diaphragm Material | Phenolic |
| Magnet Material | Ferrite |
| Magnet Weith | 35 Oz |
| Body Material | Plastic Cover |
| MEASUREMENTS | |
| Overall Diameter | 5.27" / 134mm |
| Overall Depth | 2.4" / 61mm |
| Bolt Pattern - Type | 4" / 102mm - M6 |
Setup Tips From Audio Sellerz
- Compression drivers and horns must be crossed over with a high-pass filter. Running them full range will damage them.
- A DSP makes it much easier to level match horns to the mids so the system sounds balanced instead of harsh.
