1" Throat Twist on Driver 300 Watts 1.75" Titanium Vc 8-Ohm
Sold by AudioSellerz.com
The DS18 PRO-DR1.75 is a 1" driver from the DS18 PRO line with an 8 ohm design. Horns and compression drivers are the go-to for high SPL vocals in loud pro audio builds.
DS18 Product Details
DS18 PRO-DR1.75 1" Twist On Throat Compression Driver with 1.75" Titanium VC 600 Watts 8 ohm
With the ever evolving PRO audio that DS18 provides, we are happy to present out next evolution of driver, the PRO DS1.75 Titanium Compression Driver! This 1.75-inch driver features a titanium compression diaphragm RMS rating states a handling of 300W RMS and 600W MAX power. These compression horns have a great frequency response of 500Hz to 20KHz, so they can play a much wider range than normal.
They come in 8 ohms DCR and with a sensitivity of 107dB, they will not require full power to get loud and sound great! They all come with beautiful push terminals and are surrounded by a very aesthetic red DS18 cover. These drivers will require a 1" Horn Throat to complete the package that is sold separately. These new DS18 titanium horns are sure to bring brightness to any system needing massive high-end drivers!
Highlights
- High powered DS18 high frequency driver made to blast the high frequencies for all to be heard.
- Compatible with all DS18 screw on throats of various sizes and colors so you can get the perfect look and fitment for your system.
- High quality terminals making connectivity secure and easy.
- Easily exchange voice coils in minutes.
Technical Details
| Model: | PRO-DR1.75 |
| Nominal Impedance | 8 Ohms |
| RMS Power: | 300W |
| MAX Power: | 600W |
| Sensitivity: | 107dB |
| Voice Coil Size: | 1.75" |
| Magnet Weight | 24 oz |
| Frequency Response: | 500Hz-20KHz |
| Diaphragm Material: | Titanium |
| Bolt Type | Screw Down |
| Overall Depth | 2.76" (70mm) |
Setup Tips From Audio Sellerz
- Compression drivers and horns must be crossed over with a high-pass filter. Running them full range will damage them.
- A DSP makes it much easier to level match horns to the mids so the system sounds balanced instead of harsh.
