BassHead Supply DC Audio Subwoofer Boxes

BassHead Supply DC Audio Subwoofer Boxes

Sold by AudioSellerz.com

Shop DC Audio subwoofer boxes built by BassHead Supply for specific Level series, XL SPL, XL Elite and NEO applications. Compare single and dual ported enclosures, then choose the box that matches your exact subwoofer model, size and quantity.

These are BassHead Supply-built enclosures for the DC Audio drivers named in each listing. They are not DC Audio-manufactured boxes or complete subwoofer-and-amplifier packages.

Shop all BassHead Supply enclosures | Shop DC Audio subwoofers | Shop all subwoofer boxes

Choose Your Box by DC Audio Subwoofer Model

DC Audio Level Series Enclosures

Start with the complete Level series designation, then match the woofer size and number of subwoofers. A box listed for a Level 4 driver should not be selected for a different Level series solely because the speaker openings are the same diameter.

For a Level 4 12-inch system, the single and dual enclosures below provide two specific options to compare. Check their complete dimensions before deciding which layout works in your vehicle.

DC Audio XL SPL, XL Elite and NEO Enclosures

Keep the full model name when comparing these boxes. XL SPL, XL Elite, NEO 3.5 and NEO 4.0 identify different subwoofer applications; “DC Audio XL box” or “NEO box” is not enough information to confirm the correct enclosure.

Send us the model label or a link to your exact subwoofer when you need help matching it to an enclosure listing.

Compare DC Audio Ported Enclosure Examples

Use the following BassHead Supply products as starting points for the named applications. Net volume is the listed total for the complete enclosure, not a per-subwoofer figure.

Choose by the intended subwoofer application, not whichever box has the largest volume or lowest tuning. Review the individual product page for its complete specifications and confirm compatibility with your subwoofer version before ordering.

Single vs. Dual DC Audio Subwoofer Boxes

A single enclosure is the starting point for a one-woofer system. A dual enclosure accommodates two drivers and requires planning around the complete cabinet, both subwoofers and the rest of the installation.

For example, the featured single Level 4 12-inch box measures 19.5 inches wide, 15 inches tall and 17 inches deep. The dual Level 4 12-inch box measures 33.625 inches wide, 15 inches tall and 18 inches deep.

Compare those exterior measurements with your available space, including the opening the enclosure must pass through. The final mounting area is only one part of vehicle fitment.

Airspace, Port Tuning and Physical Fit

Net internal airspace and exterior cabinet dimensions answer different questions. Outside measurements tell you how much room the box occupies; net volume accounts for the relevant space taken up by enclosure construction and internal components.

A ported enclosure also depends on the relationship between its airspace and port design. The different tuning figures in the table belong to those specific enclosures, not one universal target for every DC Audio system.

Before purchasing, check:

• Subwoofer compatibility: Exact model and version, cutout diameter, mounting depth, and clearance around the basket, magnet and moving cone.
• Enclosure requirements: Intended application, net volume, enclosure type and port specifications.
• Installation space: Exterior width, height and depth, access through the vehicle opening, and room around the port, terminals and wiring.

A subwoofer-specific box is not automatically an under-seat or vehicle-specific enclosure. Measure the installation and ask about any specification that is missing from the listing.

Birch Construction and Gray Stained Finish

The featured single and dual Level 4 12-inch boxes specify 3/4-inch birch plywood construction with a solid 1-inch front baffle. The dual model also lists a center baffle brace.

The featured XL SPL 12-inch, Level 6 15-inch and NEO 4.0 15-inch enclosures specify 1-inch plywood construction with birch veneer. All five examples list a gray stained finish and metal binding posts pre-wired with 10-gauge OFC wire.

Check the construction details on your chosen product rather than assuming every enclosure uses the same panels, bracing or cabinet dimensions.

Build Lead Time and Ordering Details

The five featured enclosure listings state a 2–3-week lead time and no refunds once the enclosures have been cut out. Review the current product page for timing and ordering conditions before purchasing.

Confirm the intended driver, quantity and vehicle measurements before production begins. A production lead time is not a guaranteed delivery date.

DC Audio Subwoofer Box FAQs

Who builds these DC Audio subwoofer boxes?

BassHead Supply builds the featured enclosures for the DC Audio subwoofer applications identified in their names. The DC Audio model name tells you which driver the enclosure is intended to accommodate.

Does an enclosure include a DC Audio subwoofer?

These are enclosure listings, not automatically loaded subwoofer packages. Check the included items on the individual product page. Browse our DC Audio subwoofers when you also need the driver.

What box should I use for a DC Audio Level 4 12?

Start by comparing the linked single and dual Level 4 12-inch enclosures. Their listed total net volumes are 1.5 and 3.0 cubic feet respectively, and both list 33 Hz tuning. Confirm the exact woofer version and vehicle fit before ordering.

Can an XL SPL box be used for an XL Elite or NEO subwoofer?

Do not assume interchangeability from the speaker size or similar specifications. Use the enclosure listing for the exact model, or ask Audio Sellerz to help check the proposed combination.

Do matching volume and tuning numbers mean two boxes are interchangeable?

Not by themselves. The intended driver, mounting clearance, cutout and complete design still need checking. Similar figures in a comparison table do not replace application-specific compatibility confirmation.

Find the BassHead Supply Enclosure for Your DC Audio Build

Choose your enclosure around the equipment you are actually using. Have the subwoofer model and version, quantity, amplifier model, vehicle and available box dimensions ready when comparing products.

Use the live chat on AudioSellerz.com for help narrowing down the options. For other brands or enclosure applications, browse the complete BassHead Supply subwoofer box collection.
